DJI FlyCart 100 (4 Battery Combo)

Redefine aerial delivery with the DJI FlyCart 100. Featuring a massive 85kg payload capacity, 12km range, and advanced safety systems including LiDAR and an integrated parachute. Built for heavy-lift logistics in all environments.

Achieve More Deliveries

Introducing the brand new DJI FlyCart 100, 85 kg^[1] payload capacity with dual battery, 2 payload systems, integrated seamlessly with a powerful developer ecosystem, redefine professional delivery and break through the operational boundaries. The intelligent and advanced Safety System enables unstoppable delivery from mountains to oceans, unlocking infinite possibilities.



Greater Load, Superior Performance

Carry heavier and reach farther, expertly balances excellent performance with power efficiency. Experience efficient delivery.

85 kg Max Payload: with Dual Battery^[1]
12 km Max Flight Distance: with 149.9 kg Takeoff Weight^[2]
82 kg Max Single-Axis Thrust: 32% Enhanced Power Efficiency^[3]
Supports Single Battery and Dual Battery Mode: 100 kg Max Payload with Single Battery^[1] | 85 kg Max Payload with Dual Batteries^[1]



Coaxial Dual-rotor

Compact size, high load capacity. Powerful propulsion system offers enhanced safety redundancy, featuring Propeller Stop Protection for added security and reliability.



62-inch Carbon Fiber Propellers

Carbon fiber propellers offer greater rigidity and lighter weight, can resist deformation even at high temperatures. With Optimized airfoil and enlarged propeller diameter, energy efficiency is improved. The upper motors are equipped with Propeller Clamps, which reduce propeller vibration for more stable flight.



Motor and ESC

Larger motors, more torque. ESC with 420A current ensure stable and reliable operation, providing faster response times.



Intelligent Deliver Control, Ultra-fast Response

FC100 supports 2 payload systems, the brand new Flagship Winch System, equipped with an Electric Hook for efficient loading and unloading. Also compatible with DJI Dual-Battery Lifting System, flexibly adapting to various delivery scenes.





DJI FlyCart 100 Flagship Winch System

Electric Hook: Electric Opening and Closing^[4]
Wireless Charging: Convenient and Hassle-Free^[5]
Real-Time Weighing: Avoid Overloading, Convenient for Settlement
Audible and Visual Alerts: Safe Loading and Unloading

Winch System Features:

High-Speed Release and Retrieve: Winch system offers both automatic and manual release and retrieval options, equipped with a rope length of 30m, it can maintain a retractable speed of 1.2 m/s with heavy loads, ensuring efficient and reliable operation.
Safe Unloading: Cargo releases automatically upon touchdown, and the hook can be remotely controlled to open, ensuring safe and precise delivery.
Auto Balance Control: The combination of a triaxial force sensor and intelligent algorithms enables minimize cargo swing and improve stability.
Cable Discard Escape: For extreme situations when hanging cargo gets trapped or tangled, discard the cable entirely with one click and let the drone free.



DJI Dual-Battery Lifting System

Auto Balance Control: Minimize swing with a single click for smooth delivery.
Rope Cut Escape: Heat and melt the rope with one click to free the drone for safe disentanglement.
Real-Time Weighing: Avoid overloading, convenient for settlement.



Deliver with Ease in Complex Environments

DJI FC100 Intelligent Safety System, equipped with new LiDAR, Millimeter-Wave Radar^[6], and Penta-Vision System. These features enable comprehensive environment awareness, allowing for precise obstacle detection^[7].

LiDAR: Capable of capturing dense spatial point cloud up to 300,000 points per second, providing a detailed view of complex terrains. It can capture obstacle more clearly than FPV during nighttime operations.
Millimeter-Wave Radar: The front radar performs 5,000 vertical scans per second combined with 360° horizontal mechanical rotation scanning, along with a down radar and a rear radar offering a more comprehensive detection range.
Penta-Vision System: The quad-vision system, pairing with an FPV low-light full-color camera, facilitates unrestricted viewing of flight scenes in front, rear, left, right, and underneath to detect obstacles more intelligently.
Night Navigation Light: Newly added front-facing high & low beams and downward supplemental light, ensuring safer nighttime operations.
DJI AirSense^[8]: A built-in ADS-B in detects and warns nearby crewed aircraft.





Comprehensive Protection for Entire Operation

From takeoff to landing, from routine to emergency situations, DJI FC100 provides comprehensive protection for personnel, drones, and cargo cross all scenes.

AR Safety Assistance^[9]: During takeoff and landing, DJI FC100 supports AR pedestrian and vehicle detection. Besides, reture-to-home mode activates landing point projection for enhanced touchdown guidance and safety.
Auto Slope Ascent: Real-time terrain perception ensures that an aircraft maintains a minimum altitude above the ground, as specified by preset safety thresholds. Safe flight in complex terrain.
Obstacle Avoidance for Cargo^[7]: Innovative obstacle avoidance algorithms ensure the aircraft and its cargo can avoid obstacles, effectively minimizing the risk of entanglement in complex scenarios.
No-roll Flight^[23]: Newly supports No-roll Flight, improving crosswind stability and enhancing fault-tolerant control performance in the event of power loss.



Integrated Parachute

The integrated parachute features multi-redundancy and can deploy at low altitude under maximum takeoff weight conditions, which can effectively slow down the aircraft's touchdown speed and minimize risk to people and property.

High-performance Canopy: corrosion-resistant, low air permeability
Independent Control: Independent power supply, independent storage
Multiple Protection: Intelligent power-on self check, propellers stop rotation before parachate opening
Safety and Reliability: Touchdown speed can be reduced to 7 m/s^[10]



Deliver Beyond Limits

DJI FC100 underwent multiple reliability tests, such as high and low temperature operation tests, wind tunnel tests, winch release and retrieve tests, electric hook opening and closing tests, and parachute opening tests. Forged through rigorous trials, the drone can fly in extreme conditions.

6000 m: Max Flight Altitude^[11]
12 m/s: Max Wind Speed Resistance^[12]
IP55: Ingress Protection Rating^[13]
-20° to 40° C: Operating Temperature^[14]





Ultra-Fast Charging, Efficient Operation

DJI FC100 supports ultra-fast charging, enables hot-swapping for seamless, uninterrupted flight operations.*
(*Accessories may vary by region, please consult your local dealer for more details.)



DB2160 Intelligent Flight Battery

Dual Battery Redundancy: In dual-battery mode, the two batteries work as backups for each other. If one battery fails during flight, another battery will keep the drone flying and avoid accidental power-off.
Battery Hot-swapping: In dual-battery mode, enabling battery hot-swapping for seamless, uninterrupted flight operations.
Battery Heating^[15]: In low-temperature, the battery is heated to its optimal operating temperature by using DJI Battery Incubator, allowing the battery to continuously retain warmth for stable performance even in extremely cold regions.



Multiple Charging Equipments, Matching Various Charging Scenes

C12000 Intelligent Power Supply: Tri-phase power input, 12000 W fast charging^[17], Adaptive power protection, 1.8 m charging cable.
C10000 Intelligent Power Supply: Single-phase power input, 9000 W fast charging^[17], Adaptive power protection, 1.5 m charging cable.
D14000iE Multifunctional Inverter Generator: 11500 W fast charging^[16], 1500 W AC output, 1.8 m charging cable.





Remote Controller and Video Transmission

Effortless Handling, Stable Transmission
DJI RC Plus 2 features a 7-inch high-brightness screen and supports Dual Controller Mode^[18], allowing two pilots to conveniently transfer control permissions to meet diverse operation requirements.

IP54: Ingress Protection Rating, Water and Dust resistant
-20° to 50° C: Operating temperature, withstands extreme weather conditions, enabling day and night operation
7-inch: High-brightness Large Screen, Peaking brightness of 1,400 nits, clear even in strong light



O4 Video Transmission

20km O4 Video Transmission^[19]: The upgraded O4 video transmission ensures constant signal availability and smoother videos.
4G Enhanced Video Transmission^[20]: Optional DJI Cellular Dongle Kit, when the O4 Video Transmission signal encounters interference but the mobile network remains strong, it can be automatically switched to mobile network transmission. Effortlessly manage complex scenarios, such as navigating mountainous obstructions.
O4 Relay: When the signal is interfered and there is no mobile network coverage, the relay function of the D-RTK3 Multifunctional Station^[21] ensures smooth operation.
Dual Controller Mode^[18]: Two pilots can control one aircraft. When the DJI FC100 is connected to two remote controllers simultaneously, both controllers have full control and video transmission capabilities. The feature allows primary and secondary pilots to switch and adjust the control to the drone in a long flight.



DJI Delivery App

Simple, Yet Extraordinary. One Touch, Instant Access.
The all-new DJI Delivery App is designed for delivery, featuring a streamlined interface and enhanced functionality. It clearly displays the drone's real-time flight status and cargo transport details. New features like A-B Route Operation Mode and AR Display significantly boost operational efficiency.

Automatic Flight: Tap-to-Fly: Freedom to choose destinations, simplicity to arrive.
A-B Route Operation Mode: After configuring the loading point A and unloading point B with a remote controller equipped with an RTK module, these settings can be synchronized to the pilot's remote controller. The pilot can then use AR projection to quickly position the point A and point B.
Multi-View Assisted Flight: The quad-vision system, combined with an FPV low-light full-color camera, enables simultaneous monitoring of the forward flight environment and downward cargo status, offering a more comprehensive view of the flight. With the addition of AR flight route and AR obstacle detection, flights are made significantly safer.
Winch System Adapts Waypoint Action: Preset the waypoint actions, enabling automatic completion of deliver tasks even in disconnected scenes.





DJI DeliveryHub

Strategic Planning, Multi-Device Collaboration
DJI DeliveryHub, a one-stop air delivery management platform, it's compatible with the entire DJI FC series. It supports efficient operation planning, comprehensive operation status monitoring, centralized team resource management, and data collection and analysis. Combining professionalism and ease of use, it facilitates efficient multi-platform collaboration and provides seamless one-stop transport management.

Operation Planning: Efficient Operations
Operation Status: Comprehensive Overview
Team Resources: Centralized Management
Intelligent Warning: Safety Protection



A Brand New Ecosystem, Ready to Shine

DJI FC100 supports PSDK, a high-power interface, and new DeliveryHub Sync 2.0, opening up more possibilities beyond delivery.

Supports PSDK: Supports external payloads^[22], allowing for easy multi-purpose use. Unlock potential applications and redefine payload capabilities.
Supports High-power Interface: Supports up to 3000 W high-power charge interface, meeting the power requirements of most external payloads. More possibilities, stemming from this.
New DeliveryHub Sync 2.0: Unlocks more DeliveryHub functions, supporting third-party platforms integration.
Terrain Follow Flight: Precise terrain variation detection enables automatic altitude hold via relative height setting. When equipped with detection payloads, measurement accuracy is significantly enhanced.



Data Security

DJI takes the security of your data seriously. We use best-in-class measures to protect the integrity of your photos, videos, flight logs, and other user data, allowing you to confidently use the full power of a cloud-based fleet management system. DJI FC100 and DJI DeliveryHub is built to maintain integrity across multiple levels of the drone and data management process – from device connection and maintenance, to data upload and transmission, to cloud service storage and operational security. DJI DeliveryHub uploads, stores and manages data on cloud servers operated by Amazon Web Services, which are compliant to ISO/IEC 27001 security certifications.



---

Notes:

[1] The 170kg maximum takeoff weight is the performance specification of the drone. Please follow local laws and regulations in actual use. In the following countries and regions the maximum takeoff weight is restricted to 150kg: Brazil, Japan, Australia, Turkey, Saudi Arabia.

[2] This data is obtained from DJI FC100 equipped with fully charged new battery at a takeoff weight of 149.9kg, flying at a constant optimal speed to 0% charge in a windless environment at 25 ° C at sea level. Results may vary depending on the environment, actual use, and firmware version. Always pay attention to app reminders during actual operation.

[3] Single-axis system efficiency (including propellers, motor, and ESC) compared to DJI FC30. Test conclusions may vary under different test conditions.

[4] Supports active control of opening and closing through APP or button.

[5] Wireless recharge requires the hook to be tightened into place. Wireless charging power limit is 45 W, and it can also be charged through Type-C, with a max charging power limit of 30 W. It is recommended to charge below the limit value.

[6] The upward rotation radar, rear single-panel radar, and downward single-panel radar are all millimeter-wave radars.

[7] The effective sensing range and its ability to avoid and bypass obstacles will vary depending on the ambient light, rain, fog, and the material, position, shape, and other properties of the obstacles. Downward sensing is used to assist in Terrain Following flight and altitude stabilization, while other directions assist with obstacle avoidance. AR safety assistance features serve only as supplementary hints, operators must confirm the surrounding environment's safety during operation.

Note 1. Downward sensing assists in Terrain Following flight. If the bottom collides with obstacles, it is considered user responsibility.

Note 2. Due to limitations in safety system performance, the aircraft cannot automatically avoid moving objects, and accidents of this nature will be attributed to user responsibility.

Note 3. Cargo obstacle avoidance is only for auxiliary flight; if the cargo and lifting cable collide with an obstacle, it is the customer's responsibility.

[8] The ADS‑B receiver is only included with the Flagship Winch System.

[9] AR safety assistance features serve only as supplementary hints; operators must confirm the surrounding environment's safety during operation. Detection performance of sensors such as quad-vision and FPV cameras may vary depending on the ambient light, rain, fog, and the material, position, shape, and other properties of the obstacles.

[10] When DJI FC100 flies in a 25° C windless environment at sea level with a full payload, the lowest height for opening the parachute is 100 m and the terminal descent speed 7 m/s.

[11] An altitude of 6,000 meters is the maximum safe altitude for DJI FC100 flying without payload.

[12] During takeoff and landing, DJI FC100 can resist a maximum wind speed of 12 m/s.

[13] The protection rating is not permanent and may decline due to aging and wear caused by long-term use. The protection rating does not apply to the propulsion system. After a flight in rain, it is recommended to keep it idling on the ground for 1 minute to prevent corrosion or rust to afflict the propulsion system (precipitation of more than 24.9 mm within 24 hours).

[14] Measured with estimated solar radiation of 960 W/m². Long-term exposure to high temperatures may shorten the service life of certain components.

[15] The battery heating function requires the additional purchase of a battery Incubator.

[16] The output power of the charging station may be affected by altitude and fuel quality.

[17] Affected by the local power grid environment, such as distance, wire material, and wire gauge, the output power may vary.

[18] The second remote controller is optional and needs to be purchased separately.

[19] The 20 km transmission distance is measured with FCC compliance. The maximum Video Transmission communication distance with SRRC compliance is 12 km. The maximum Video Transmission communication distance with CE/MIC compliance is 10 km. The above data shows the farthest communication range for one-way, non-return flights under each standard, and is measured outdoors in an open, interference-free environment. During your flight, please pay attention to RTH reminder on the DJI Delivery App.

[20] Optional accessory. Need to purchase separately. Operating frequency varies among countries and regions. Refer to the local laws and regulations for more information.

[21] Optional accessory. Need to purchase separately.

[22] When connecting an external payload, you need to purchase the DJI FC100 PSDK Connection Cable Combo separately.

[23] This feature will be supported via a future Firmware Update. Please stay tuned for relevant firmware update in the remote controller and on the official website.
